ACVT16C

EV CHARGING POINT MODULAR BOX 3P+N 16A POP+SPD

Print to PDF

Code 030ACVT16C
EAN 8430892352802
Combiner box technical data
MCB - Circuit breaker 16 A
Curve C
Breaking capacity EN 60898-1 6 kA
RCCB type A
Combiner box type AC
Network type 3P+N
Operating voltage (Ue) 415 V AC
Surge protector Class II
Diferential type 30mA
Inputs current rating 16 A
Surge protector code -P20
Surge protector type II
Nominal discharge current (In) 15 kA
Maximum discharge current (Imax) 40 kA
Protection level at In (Up) 2 kV
IP IP65 - IEC 60529
IK IK08 - IEC 62262
Standards IEC EN 6143-1/2
Diagrams
Electric diagram Diagrama eléctrico
Dimensions
Product height 231 mm
Product width 238 mm
Product length 118 mm
Logistic Data
Customs code 85371098
