STM11025D15

1 STRING MODULAR COMBINER BOX PV FUSE 15A + SURGE PROTECTOR I+II
PV modular combiner box 1 string + fuseholder and fuse 15A gPV + switch-disconnector 25 A + surge protector class I+II maximum voltage 1000Vdc, for safe installations. Double insulation class II polycarbonate box suitable for outdoor use with high impact protection (IK08). Dimensions 231x238x118mm.

Print to PDF

Code 029STM11025D15
EAN 8430892334730
Combiner box technical data
Surge protector Class I+II
No. of strings per tracker 1
Number of MPPT trackers 1
Fuse current 15 A
Maximum voltage (Uoc max) 1000 V
PV current (In) 25 A
Surge protector code PST31APV
Surge protector type I+II
Maximum impulse current (Iimp) 6.25 kA
Nominal discharge current (In) 15 kA
Maximum discharge current (Imax) 40 kA
Protection level at In (Up) 2.6/4.6 kV
IP IP65 - IEC 60529
IK IK08 - IEC 62262
Standards IEC EN 6143-1/2
Dimensions
Product height 231 mm
Product width 238 mm
Product length 118 mm
Logistic Data
Customs code 85371098
