SP101016P15

PV COMBINER BOX 10 STRINGS - FUSE 15A -SWITCH DISCONNECTOR 160A + SURGE PROTECTOR
PV combiner box for 10 strings + fuseholder and 15A gPV fuse + switch-disconnector 160A +surge protector class II maximum voltage 1000Vdc, to set up reliable and safe installations. Box in selfextinguishing glass reinforced polyester with cover in transparent polycarbonate. Enclosure bottom part equipped with individual cable glands for each string, for the load output and the earthing output. Protection screens on the switch live parts. Safety signs according to standard requirements. Dimensions 540x201x540mm.
Code 029SP101016P15
EAN 8430892302692
Combiner box technical data
Operating voltage (Ue) 1000 V DC
Surge protector Class II
Inputs current rating 1X160A
No. of strings per tracker 10
Fuse current 15 A
Maximum voltage (Uoc max) 1000 V
Surge protector code 1 x PST31PV
Surge protector type II
Max. continuous operating voltage (Ucpv) 1060 VDC
Nominal discharge current (In) 20 kA
Maximum discharge current (Imax) 40 kA
Protection level at In (Up) 3,6 kV
IP IP66 - IEC 60529
IK IK09 - IEC 62262
Standards IEC EN 6143-1/2
Dimensions
Product height 540 mm
Product width 540 mm
Product length 201 mm
Logistic Data
Customs code 85371098
