SFF140/4

FIREFIGHTER SAFETY SWITCH 4 STRINGS

Firefighter Switch SFF140 for 4 Strings, is a safety solution designed to protect firefighters and emergency teams operating in fires or critical situations in photovoltaic installations. This device enables a fast and secure disconnection of solar systems, minimizing the risk of electrocution during rescue operations. Dimensions: 370x203x88 mm in a compact PC+ABS enclosure

Code 029SFF140/4
EAN 8430892355513
Dimensions
Product height 370 mm
Product width 203 mm
Product length 88 mm
SFF Technical Data
Number of Strings 4
String voltage (Ue) 300...1500 VDC
AC disconnection circuit 230 V - 30 mA
String current 600 V 50 A
String current 1000 V 40 A
String current 1500 V 20 A
Temperature automatic shutdown 70ºC / 158ºF
Safe quick connection MC4
Protection degree IP66
Enclosure material PC-ABS
Base colour RAL 9006
Cover colour RAL 7038
Weathrproof ventilation valv 1
Standards IEC 60947-3 - DC-PV1
