67430630

NH FUSE WITH INDICATOR 630A.AM S4
NH blade fuse size 4 Nominal current of 630A with protection curve class AM. Suitable for the protection of engines, transformers and equipment with high boot tips. For tensions up to 500V a Rupture capacity of 120KA in short-circuit protection. Ceramic highly resistant to thermal shocks and pressure. Contacts in copper with silver bath and specially for easy introduction to the fuse and incoming base for fixing the screws.
Code 01867430630
EAN 8430892110327
Fuse data
Fuse type NH
Operating voltage 690 V
Utilisation category aM
Breaking capacity 120 kA
Fuse indicator Si / Yes
Standards IEC 60269-1/2
Technical data
Standard IEC 60269-2
Size 4
