YL861C101
MOTORISED CHANGEOVER SWITCH 1-0-2 2P 250A INCOMING ON BOTTOM. 12V DC
Motorised changeover switch 1-0-2 , 2 poles 250A with motor unit supply 80-230Vac . The supply incoming cables are connected on the bottom side of the unit and the load outgoing cables are connected on the top side. Size D3 dimensions 185x261x113, includes auxiliary contact 12A. Back plate mounting. Built-in internal links, mechanical and electrical interlock. Local emergency operation, includes removable padlockable handle. Display for switch position indication and operation counter.Impulse control logic. Protection against supply voltage failure . Terminal connection with tubular cable lugs M8 up to 120mm2.
