55MPV4025

MOTORISED ON-OFF LOAD BREAK SWITCH PV 250A 1000VDC
Motorized Load Break Switch 250A 1000Vdc. Size B4 4 poles (2 poles per polarity) 160x395x245. Power supply for motorized 230V (166/332). The high performance of the materials used gives it a high thermal and dynamic resistance. Optional accesories with serial bridges, auxiliary contacts, covers, protection screens, phase barriers.
Code 01755MPV4025
EAN 8430892293549
Dimensions
Product height 160
Product width 395
Product length 244,5
Technical data
Nr. Poles 4
Air thermal rating (Ith) 250 A
Impulse voltage (Uimp) 12 kV
Maximum Cu cable cross-section

120
Maximum Cu busbar width

32
Tightening torque 20/- Nm
Connection screws M10
DC21B 250 A
Standard IEC 60947-3
