CP004040
SWITCH 4P 400A POLIESTER BOX
| Code | 017CP004040 |
| EAN | 8430892169578 |
| Nr. Poles | 4 |
| Air thermal rating (Ith) | 400 A |
| Impulse voltage (Uimp) | 12 kV |
| Minium Cu cable cross-section | 185 mm2 |
| Maximum Cu cable cross-section | 240 mm2 |
| Maximum Cu busbar width | 40 mm2 |
| Tightening torque | 20/- Nm |
| Prostpective shortcircuit current (rms) | 100 kA |
| Associated fuse rating | 400 A |
| Rated short-time withstand current 1s (Icw) | 13 kA |
| Standard | IEC 60947-3 |
