55PV4050
SWITCH SIRCO 4P 500A 1000VDC
Code | 01755PV4050 |
EAN | 8430892230759 |
Nr. Poles | 4 |
Operational rating (Ie) | 500 A |
Air thermal rating (Ith) | 500 A |
Impulse voltage (Uimp) | 12 kV |
Maximum Cu cable cross-section | 2x185 mm2 |
Maximum Cu busbar width | 32 mm2 |
Tightening torque | 10 Nm |
