55AC4160
ON-OFF LOAD BREAK SWITCH 4P x 1600A
Code | 01755AC4160 |
EAN | 8430892292962 |
Nr. Poles | 4 |
Air thermal rating (Ith) | 1600 A |
Impulse voltage (Uimp) | 12 kV |
Minimum Cu busbar cross-section | 3x100x5 mm2 |
Maximum Cu cable cross-section | 6x185 mm2 |
Maximum Cu busbar width | 100 mm2 |
Tightening torque | 40/45 Nm |
Prostpective shortcircuit current (rms) | 100 kA |
Associated fuse rating | 2x800 A |
Rated short-time withstand current 1s (Icw) | 50 kA |
Standard | IEC 60947-3 |
