Code 01755AC3100
EAN 8430892292863
Technical data
Nr. Poles 3
Air thermal rating (Ith) 1000 A
Impulse voltage (Uimp) 12 kV
Minium Cu cable cross-section

2x240 mm2

Minimum Cu busbar cross-section

2x50x5 mm2

Maximum Cu cable cross-section

4x185 mm2

Maximum Cu busbar width

63 mm2

Tightening torque 40/45 Nm
Prostpective shortcircuit current (rms) 100 kA
Associated fuse rating 1000 A
Rated short-time withstand current 1s (Icw) 35 kA
Standard IEC 60947-3
