55AC3020
ON-OFF LOAD BREAK SWITCH 3P x 200A
Code | 01755AC3020 |
EAN | 8430892284547 |
Nr. Poles | 3 |
Air thermal rating (Ith) | 200 A |
Impulse voltage (Uimp) | 8 kV |
Minium Cu cable cross-section | 70 mm2 |
Maximum Cu cable cross-section | 95 mm2 |
Maximum Cu busbar width | 32 mm2 |
Tightening torque | 20/- Nm |
Prostpective shortcircuit current (rms) | 80 kA |
Associated fuse rating | 200 A |
Rated short-time withstand current 1s (Icw) | 9 kA |
Standard | IEC 60947-3 |
