AC556B107

ON-OFF SWITCH 6P.200A. IP65 ENCLOSURE
4-pole 200A safety switch in IP65 enclosure. E2 sheet steel enclosure suitable for indoor or outdoor use in RAL7035 grey color, dimensions 250x300x200. High impact resistance IK10. Base mounted switch with extended shaft and interlock in closed position. Black / grey padlockable handle (up to 4 padlocks of 8mm diameter). Earthing terminal. Cable lug terminal connection for 90 mm² cable

Print to PDF

Code 009AC556B107
EAN 8430892163484
Dimensions
Logistic Data
Customs code 85365080
Etim Code EC000216
Packing units 1
Technical data
Nr. Poles 6
Operational rating (Ie) 200 A
Air thermal rating (Ith) 200 A
Wire section flexible

95 mm2

Connection screws M8
Terminal Terminal
Max. fuse protection (gG/aM)

200 A (415 V)

200 A (500 V)

Conditional shortcircuit current (Icc)

8 kA (415 V)

8 kA (500 V)

Insulating voltage (V~) 690
Insulating voltage (V...) 600
Dummy AC-21A

55 kW (3x230 V)

110 kW (3x415 V)

132 kW (3x500 V)

Mixed load AC-22A

45 kW (3x230 V)

90 kW (3x415 V)

110 kW (3x500 V)

Motor load AC-23A

38 kW (3x230 V)

65 kW (3x415 V)

80 kW (3x500 V)

Standard IEC 60947-3
Enclosure type METAL
