ABA632107

CONMUTADOR 4P 25A + AUX. NA D0 BLOQ.CANDADO ROJO/AMARILLO CAJA PCB
4-pole 25A + NO auxiliary contact changeover switch in IP65 enclosure. E0 polycarbonate enclosure suitable for indoor or outdoor use, RAL7035 grey cover and black base, dimensions 100x130x90. M20 easy-open knockouts, two on top, two on bottom and two at the base. 4 points surface fixing. Base mounted switch with extended shaft and interlock in closed position. Red / yellow padlockable handle (up to 4 padlocks of 8mm diameter). Earthing terminal. Connection with cage terminals for 2.5-6 mm² cable.

Print to PDF

Code 009ABA632107
EAN 8430892334877
Logistic Data
Packing units 1
Technical data
Nr. Poles 4
Air thermal rating (Ith) 25 A
Cable cross-section (AWG) 6
Wire section rigid

6 - 25 mm2

Wire section flexible

6 - 16 mm2

Standard IEC 60947-3
Enclosure type PLASTIC
Auxiliary 1NO
