AB556C107

ON-OFF SWITCH 6P.250A. IP65 ENCLOSURE
4-pole 250A safety switch in IP65 enclosure. E2 sheet steel enclosure suitable for indoor or outdoor use in RAL7035 grey color, dimensions 250x300x200. High impact resistance IK10. Base mounted switch with extended shaft and interlock in closed position. Red / yellow padlockable handle (up to 4 padlocks of 8mm diameter). Earthing terminal. Cable lug terminal connection for 110 mm² cable

Print to PDF

Code 009AB556C107
EAN 8430892235464
Dimensions
Logistic Data
Customs code 85365080
Etim Code EC000216
Packing units 1
Technical data
Nr. Poles 6
Operational rating (Ie) 250 A
Air thermal rating (Ith) 250 A
Wire section flexible

120 mm2
Connection screws M8
Terminal Terminal
Max. fuse protection (gG/aM)

250 A (415 V)

250 A (500 V)
Conditional shortcircuit current (Icc)

8 kA (415 V)

8 kA (500 V)
Insulating voltage (V~) 690
Insulating voltage (V...) 600
Dummy AC-21A

75 kW (3x230 V)

132 kW (3x415 V)

160 kW (3x500 V)
Mixed load AC-22A

55 kW (3x230 V)

110 kW (3x415 V)

132 kW (3x500 V)
Standard IEC 60947-3
Enclosure type METAL
