| Code | 009A-5606100 |
| EAN | 8430892102421 |
| Customs code | 85365080 |
| Etim Code | EC000216 |
| Packing units | 1 |
| Package height (mm) | 107 |
| Package width (mm) | 82 |
| Package length (mm) | 82 |
| Nr. Poles | 1 |
| Operational rating (Ie) | 63 A |
| Air thermal rating (Ith) | 70 A |
| Cable cross-section (AWG) | 16 - 1 |
| Wire section flexible | 16 - 50 mm2 |
| Tightening torque | 3,5 Nm |
| Connection screws | M8 |
| Terminal |  |
| Max. fuse protection (gG/aM) | 63/63 A (415 V) 63/63 A (500 V) |
| Conditional shortcircuit current (Icc) | 8 kA (415 V) 8 kA (500 V) |
| Insulating voltage (V~) | 690 |
| Insulating voltage (V...) | 600 |
| Dummy AC-21A | 22 kW (3x230 V) 45 kW (3x415 V) 45 kW (3x500 V) |
| Mixed load AC-22A | 18,5 kW (3x230 V) 37 kW (3x415 V) 45 kW (3x500 V) |
| Motor load AC-23A | 15 kW (3x230 V) 22 kW (3x415 V) 30 kW (3x500 V) |
| UL Electric characteristics | 5 hp 1-fase (110-120 V) 10 hp 1-fase (220-240 V) 15 hp 3-fase (220-240 V) 25 hp 3-fase (380-415 V) 30 hp 3-fase (440-480 V) 32 hp 3-fase (550-600 V) |
| Standard | IEC 60947-3 UL 508 |
| Handle type | Directo |
